BAT46W The CJ BAT46W is a Schottky signal diode designed for general-purpose rectification. It offers a 100V reverse voltage and 150mA average forward current.
Mfr Part #:

BAT46W

Available from 2 distributors
Mfr Name: CJ
CJ
The CJ BAT46W is a Schottky signal diode designed for general-purpose rectification. It offers a 100V reverse voltage and 150mA average forward current.
✓ Total Stock: 3,750 pcs
$ Price Range: $0.40

BAT46W Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Smaxon Electronics ✓
Non-Authorised Inventory information
3,000 pcs
On Request
3000 pcs On Request 1 On Request On Request 21+ On Request On Request
Xingangxin ✓
Non-Authorised Inventory information
750 pcs
On Request
750 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

BAT46W Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Capacitance
Configuration
Diode Type
Mounting Type
Number of Elements
Operating Temperature
Reverse Current
Technology
View Similar Products (0)

BAT46W Description

Short technical summary and product information.

The CJ BAT46W is a Schottky barrier diode in a compact SOD-123 surface mount package. It is designed for signal rectification applications and features a maximum reverse voltage of 100V and an average forward current of 150mA.



With a typical forward voltage of 450mV at 10mA, this diode is suitable for various electronic circuits. The operating temperature range is from -55°C to 125°C, making it robust for different environmental conditions. The component is constructed with silicon and has a plastic/epoxy package body.



Key electrical characteristics include a maximum power dissipation of 200mW and a capacitance of 20pF at 0V and 1MHz. The BAT46W is a single-element diode configured for single-use applications.



This surface mount diode is ideal for applications requiring efficient rectification and low forward voltage drop. Its small outline package makes it suitable for space-constrained designs.

BAT46W Quick Information

Product Type: Signal Diode
Canonical Name: BAT46W Schottky Barrier Diode
Subcategory: Rectifier

BAT46W Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

BAT46W Estimated Pricing

Qty Low High
1+ $0.40 $0.40

Estimated market price range - modelled values for guidance only, not live distributor offers.

BAT46W Features

  • 100V maximum reverse voltage.
  • 150mA average forward current.
  • Low 450mV forward voltage.
  • Operating temperature -55°C to 125°C.
  • Compact SOD-123 surface mount package.

BAT46W Applications

  • Suitable for signal rectification.
  • Ideal for general-purpose diode applications.
  • Used in compact electronic designs.
  • Effective in low-power circuits.

BAT46W FAQs

7 frequently asked questions generated from this part’s specifications.
What is the maximum reverse voltage of the BAT46W?

100 V.

What is the average forward current rating?

150 mA (DC).

What is the forward voltage at 10 mA?

Maximum 450 mV.

What package is the BAT46W available in?

SOD-123 surface mount package.

What is the operating temperature range?

-55°C to 125°C.

What is the typical junction capacitance?

20 pF at 0 V, 1 MHz.

What is the peak non-repetitive surge current?

0.75 A.
