| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
742 pcs
|
742 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Diode Capacitance | |
| Forward Current | |
| Junction Temperature | |
| Mounting Type | |
| Operating Temperature Range | |
| Reverse Current | |
| Storage Temperature | |
| Tape & Reel |
The Infineon BAS70-07 is a Silicon Schottky Diode suitable for high-speed switching, circuit protection, and voltage clamping applications. It offers a maximum reverse voltage of 70V and a maximum forward current of 70mA.
Key electrical characteristics include a breakdown voltage of 70V at 10µA, a maximum reverse leakage current of 0.1µA at 50V, and a typical forward voltage of 375mV at 1mA, 705mV at 10mA, and 880mV at 15mA. The diode capacitance is a maximum of 2pF at 1MHz and 0V reverse bias, with a typical forward resistance of 34 Ohms at 10mA and 10kHz.
This component operates within a temperature range of -55°C to 125°C and has a junction temperature limit of 150°C. The BAS70-07 is housed in a SOT343 surface mount package and comes on tape and reel with a standard package quantity of 77 units.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
70V.
70mA.
At 1mA maximum 375mV, at 10mA maximum 705mV, at 15mA maximum 880mV.
100mA for t ≤ 10ms.
250mW.
SOT343 surface mount.
2pF maximum at 0V bias.
