The Balluff BAE00TP is an enclosed AC/DC converter designed for ITE (Commercial) applications. It provides a power output of 144W and a current rating of 6A, with a voltage of 3 kV.
Key features include adjustable output and an IP67 rating, making it suitable for demanding environments. The converter has an efficiency of 91% and operates within a temperature range of -25°C to 70°C (with derating).
This unit is designed for chassis mounting and has a single output. It is approved by CE and cURus agencies. The dimensions are 139.0mm in length, 85.4mm in width, and 72.5mm in height.
The BAE00TP is designed for chassis mounting.
The BAE00TP operates from -25°C to 70°C with derating.
The BAE00TP provides a single 24V output at 144W with a rated current of 6A.
The BAE00TP has an efficiency rating of 91%.
The BAE00TP is approved to CE and cURus standards.
The BAE00TP measures 139.0mm x 85.4mm x 72.5mm.
The BAE00TP includes an adjustable output and an IP67-rated enclosure.
