| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,140 pcs
|
2140 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Mounting Type | |
| Number of Elements | |
| Operating Temperature | |
| Output Type | |
| SVHC Present | |
| Supplier Device Package | |
| Termination Style | |
| Type | |
| Voltage |
The BA2903YFVM-CTR is a dual general-purpose comparator in ROHM's BA2903Y series, designed for automotive ground-sense applications. Each of the two comparators provides an open-collector output. The device is AEC-Q100 Grade 1 qualified and operates over the full -40°C to +125°C automotive temperature range.
Electrical specifications include a wide operating supply voltage of 2V to 36V (single supply) or ±1V to ±18V (split supply). Typical supply current is 0.6mA, with 50nA input bias current and 5nA input offset current. Input offset voltage is typically 4mV at 5V, with a maximum of 5mV over the full temperature range.
The comparator is housed in an MSOP-8 package measuring 2.90mm x 4.00mm x 0.90mm, with a surface-mount gull-wing termination. The ground-sensing input stage supports direct ground-level sensing for automotive loads. Applications include engine control units, electric power steering, and anti-lock braking systems.
Single supply: 2V to 36V; split supply: ±1V to ±18V.
MSOP-8 (8-MSOP) surface-mount package, dimensions 2.90mm x 4.00mm x 0.90mm.
-40°C to +125°C.
Listed as RoHS3 compliant in existing data, but unverified; confirm with manufacturer documentation.
Yes, AEC-Q100 Grade 1 qualified.
0.6mA typical per datasheet.
Two independent comparator elements.
