Mfr Part #:

BA1-B0-24-630-H22-E

The Littelfuse Inc. BA1-B0-24-630-H22-E is a single-pole circuit breaker with a 30A current rating and 250V AC voltage rating. It features a magnetic (hydraulic delay) mechanism and a lever actuator.

Stock on Request

BA1-B0-24-630-H22-E Description

Short technical summary and product information.

The Littelfuse Inc. BA1-B0-24-630-H22-E is a single-pole circuit breaker designed for reliable circuit protection. It operates with a current rating of 30A and a voltage rating of 250V AC, with a DC voltage rating of 80V.

This breaker utilizes a magnetic (hydraulic delay) mechanism for its tripping action, providing consistent performance. It is designed for panel mounting and features a simple lever actuator for manual operation. The unit is approved by CCC, CSA, TUV, and UL, indicating compliance with various international safety standards.

Key specifications include a 1-pole configuration and no illumination. The RoHS status is reported as RoHS3 Compliant, and the Moisture Sensitivity Level (MSL) is 1 Unlimited. REACH status is listed as REACH Unaffected. This circuit breaker is suitable for applications requiring robust overcurrent protection in a panel-mounted configuration.

BA1-B0-24-630-H22-E Quick Information

Product Type: Circuit Breaker

Canonical Name: Carling Technologies BA1-B0-24-630-H22-E Magnetic Hydraulic Delay Circuit Breaker

Subcategory: Circuit Breaker

BA1-B0-24-630-H22-E Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

BA1-B0-24-630-H22-E Features

30A current rating for robust protection.
250V AC voltage rating suitable for many applications.
Magnetic (hydraulic delay) breaker type.
Panel mount design for easy installation.
Approved by CCC, CSA, TUV, and UL.

BA1-B0-24-630-H22-E Applications

Ideal for overcurrent protection.
Suitable for panel mounting.
Used in industrial control systems.
Applicable in power distribution units.

BA1-B0-24-630-H22-E FAQs

7 frequently asked questions generated from this part’s specifications.

What is the current rating of the BA1-B0-24-630-H22-E?

30A.

What are the voltage ratings?

250V AC and 80V DC.

How many poles does this circuit breaker have?

1 pole.

What type of actuator does it use?

Lever actuator.

What mounting type is supported?

Panel mount.

What agency approvals does it have?

CCC, CSA, TUV, UL.

What is the breaker type?

Magnetic (Hydraulic Delay).
