| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
14 pcs
|
14 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance | |
| Climatic Category | |
| DC Operating Voltage | |
| DC Spark-over Voltage (Maximum @ w. capacitors) | |
| Fail Short | |
| Front of Wave Spark-over Voltage (Maximum @ Arrester only, after service life) | |
| Front of Wave Spark-over Voltage (Maximum @ Arrester only, initial) | |
| Front of Wave Spark-over Voltage (Maximum @ w. capacitors, after service life) | |
| Front of Wave Spark-over Voltage (Maximum @ w. capacitors, initial) | |
| Impulse Discharge Current (8 | |
| Impulse Discharge Current (Nominal @ 10/1000 µs, 300 operations) | |
| Impulse Discharge Current (Nominal @ 10/350 µs, 10 operations) | |
| Impulse Discharge Current (Nominal @ 10/350 µs, 100 operations) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature Range | |
| Tape & Reel | |
| Tolerance | |
| Voltage | |
| Weight |
The TDK B88069X2863T302 is a stacked gas discharge tube arrester from the LN8A-A1400DC-5 series. It features a nominal DC spark-over voltage of 1400 V and a maximum front of wave spark-over voltage of 2300 V initially and 3000 V after service life. The device is rated for impulse discharge currents of 20 kA (8/20 µs, 10 operations) and 4 kA (10/350 µs, 10 operations).
Designed for DC power supply protection at 60 V operating voltage, this arrester offers very low capacitance (<1 pF at 1 MHz) and high insulation resistance (>10 GΩ at 100 VDC). The 5-pole configuration supports multi-line protection in a compact cylinder no-lead package with user-defined mounting.
The arrester operates over a temperature range of -40 to +125 °C and is classified under climatic category 40/125/21. It is RoHS-compatible and weighs approximately 5.5 g.
| Qty | Low | High |
|---|---|---|
| 300+ | $9.86 | $9.86 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal DC spark-over voltage is 1400 V for the arrester only, with a maximum of 1250 V when used with capacitors.
The arrester is rated for 20 kA (8/20 µs waveform, 10 operations) and 4 kA (10/350 µs, 10 operations).
The operating temperature range is -40 to +125 °C.
The datasheet indicates the device is RoHS-compatible.
The maximum capacitance is less than 1 pF at 1 MHz.
The DC operating voltage is 60 V with a tolerance of ±20 V.
