| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4 pcs
|
4 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Input Voltage Max | |
| Input Voltage Min | |
| Isolation Voltage | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current (Continuous) | |
| Output Current (Peak) | |
| Output Power (Continuous) | |
| Output Power (Peak) | |
| Output Voltage - Nominal | |
| Output Voltage Max | |
| Output Voltage Min | |
| Package / Case | |
| Power (Watts) | |
| Storage Temperature | |
| Termination Style | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Vicor B048F240T30 is a high-efficiency bus converter module from the VI Chip BCM family. It operates from a 38 to 53 Vdc primary bus and delivers an isolated 19.0 to 26.5 Vdc output (nominal 24 Vdc) at up to 12.5 A continuous (18.8 A peak for 1 ms). Continuous output power is 300 W, with a peak capability of 450 W for 1 ms.
This module achieves typical efficiency of 96% (95.8% specified) and provides 2250 Vdc input-to-output isolation. It features remote on/off control and undervoltage lockout (UVLO). The operating junction temperature range is -40°C to 125°C (T-Grade).
The B048F240T30 uses through-hole termination and is housed in a compact module package measuring 32.5 mm x 22.0 mm x 6.7 mm, weighing 15 g. It is designed for commercial ITE applications and can power non-isolated point-of-load converters or serve as an independent 19.0-26.5 V source.
The input voltage range is 38 V to 53 Vdc.
The nominal output voltage is 24 Vdc, adjustable from 19.0 V to 26.5 V. Continuous output current is 12.5 A, with a peak of 18.8 A for 1 ms.
The operating junction temperature range is -40°C to 125°C (T-Grade).
The part is listed as RoHS3 Compliant, but this status is unverified.
The module uses through-hole termination and is housed in a Module package measuring 32.5 mm x 22.0 mm x 6.7 mm.
The isolation voltage is 2250 Vdc from input to output.
