| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Efficiency | |
| Mounting Type | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Power | |
| Output Voltage | |
| SVHC Present |
The MINM AYM-60S12 is a 60W AC-DC power module from the AYM-60 series, designed for industrial and medical applications. It offers a universal input voltage range of 85-264VAC and a nominal output voltage of 12VDC.
Key electrical specifications include a maximum output power of 60W and a typical efficiency of 87% at maximum load with 230VAC input. The module is built to withstand a wide operating ambient temperature range from -40℃ to +80℃, ensuring reliable performance in demanding environments. It also features 4000VAC I/O isolation with reinforced insulation.
Designed for PCB mounting, this fully encapsulated plastic case power module meets stringent safety and EMC standards, including EMI Emission EN 55011/32 Class B and EMC Immunity EN 61000-4-2,3,4,5,6,8,11. It also holds approvals for medical safety (2xMOPP per IEC/EN 60601-1) and industrial applications (UL508).
This power module is suitable for integration into products requiring robust power conversion with high safety and reliability standards.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.17 | $1.17 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 85-264VAC or 120-370VDC.
The output voltage is 12VDC with a maximum output power of 60W.
The operating temperature range is -40°C to +80°C.
Typical efficiency is 87% at maximum load with 230VAC input.
The I/O isolation is 4000VAC with reinforced insulation.
The module is designed for PCB mounting with a fully encapsulated plastic case.
The no-load power consumption is 0.5W maximum.
