| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
965 pcs
|
965 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance | |
| Country of Origin | |
| Diameter | |
| Dimensions | |
| Dissipation Factor | |
| Failure Rate | |
| Length | |
| Mounting Type | |
| Tape & Reel | |
| Technology | |
| Tolerance | |
| Voltage |
The Cornell Dubilier AVE476M25E16T-F is an aluminium electrolytic capacitor from the AVE series, offering a capacitance of 47µF and a voltage rating of 25V dc. This component is designed for surface mount applications and features a compact size with dimensions of 8 x 6.5mm.
Key electrical specifications include a tolerance of ±20%, a ripple current of 155 mA @ 120 Hz/+85°C, and a leakage current of 0.01 CV or 3 μA. The capacitor has an equivalent series resistance of 4.94 Ω @ 120 Hz/+20°C and a dissipation factor of 0.14 % @ 120 Hz/+20°C. It is polarized and suitable for general purpose filter and bypass applications.
Operating within a temperature range of -40°C to +85°C, the AVE476M25E16T-F has a specified lifetime of 2000 hours at operating temperature and 1000 hours shelf life. The lead pitch is 2.3mm, facilitating automatic mounting and reflow soldering. This series offers low impedance and wide voltage ratings, providing a cost-effective alternative to tantalum capacitors.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.20 | $1.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
-40°C to +85°C.
47 µF.
25 V dc.
±20%.
Surface mount.
2000 hours at +85°C, with a shelf life of 1000 hours.
AVE series from Cornell Dubilier Electronics.
