The Advantech Corp AU6802N1 is a Resolver to Digital (R/D) conversion IC designed to convert resolver signals into digital absolute position angle signals. This IC is suitable for a wide range of applications, including vehicle, robot, and machine tool systems, when used with brushless resolvers.
Key specifications include selectable resolutions of 10-bit (1024) or 12-bit (4096), with maximum angular velocities of up to 240,000 min⁻¹ for the 10-bit resolution and 60,000 min⁻¹ for the 12-bit resolution. It boasts a conversion accuracy of ±4 LSB Max. and a maximum angular acceleration of 3,000,000 rad/sec². The device operates within a wide temperature range of -40°C to +125°C.
This R/D converter features a single DC5V power supply and includes an integrated oscillator for exciting the resolver at 10/20 kHz. The output is a binary code parallel format, compatible with 10/12-bit bus standards and positive logic. The AU6802N1 is available in a compact 52-pin TQFP package with a pin interval of 0.65mm and a mass of only 0.3 grams, making it suitable for space-constrained applications. It also incorporates built-in test and abnormality detection functions for enhanced reliability.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The AU6802N1 offers selectable resolutions of 1024 (10-bit) or 4096 (12-bit).
The maximum tracking rate is 240,000 min⁻¹ for 10-bit resolution and 60,000 min⁻¹ for 12-bit resolution.
The operating temperature range is -40°C to +125°C.
The AU6802N1 requires a single DC5V power supply with a tolerance of ±10%.
