| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Apparent Power | |
| Continuous Output Current (Nominal @ 380 V) | |
| Continuous Output Current (Nominal @ 460 V) | |
| Control | |
| Current | |
| EMC Filter | |
| IP Degree of Protection | |
| Interface | |
| Line Current (Nominal @ 380 V) | |
| Line Current (Nominal @ 480 V) | |
| Maximum Transient Current | |
| Motor Power (Nominal) | |
| Motor Type | |
| Mounting Type | |
| Number of Motors | |
| Operating Temperature | |
| Output Frequency | |
| Output Voltage | |
| Prop 65 | |
| Rated Supply Voltage | |
| Speed Accuracy | |
| Speed Range | |
| Storage Temperature | |
| Supply Frequency | |
| Supply Voltage Limits | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Wattage |
The Schneider Electric ATV212H075N4 is a variable speed drive from the Altivar 212 range, specifically designed for asynchronous motors. It offers a motor power of 0.75kW (1hp) and operates on a 3-phase supply voltage ranging from 380 to 480V AC.
This drive features a continuous output current of 2.2A and an output frequency range of 0.5 to 200 Hz. It includes an integrated Class C2 EMC filter and provides an IP21 degree of protection, making it suitable for applications in ventilation, pumping, and air conditioning systems within HVAC environments. The drive supports Modbus communication protocol.
With a chassis mount type, the ATV212H075N4 has an operating temperature range of -10°C to 50°C. It is designed for AC motors and supports a single motor.
Environmental compliance includes RoHS3 compliance and REACH unaffected status. The product is also subject to California Proposition 65 regulations regarding lead and lead compounds.
| Qty | Low | High |
|---|---|---|
| 1+ | $512.37 | $512.37 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The motor power is 0.75 kW or 1 hp.
The rated supply voltage range is 380 to 480 V AC.
The continuous output current is 2.2 A.
The operating temperature range is -10°C to 50°C.
The IP degree of protection is IP21.
Yes, it is RoHS3 Compliant.
The Moisture Sensitivity Level is 1.
