| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
200 pcs
|
200 pcs | On Request | 1 | On Request | On Request | 1813 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Number of Gates | |
| SVHC Present |
The Microchip ATF16V8BQL-15SU is a high-performance complex programmable logic device (CPLD) from the ATF1502AS(L) series. It offers 150 logic gates and 8 macro cells, with 8 user I/O pins available for interfacing.
This device supports in-system programmability and re-programmability, making it suitable for various design iterations. It operates within a supply voltage range of 4.75V to 5V and has a maximum internal frequency of 62 MHz. The maximum propagation delay is 15 ns.
Packaged in a 20-pin SOIC surface-mount package, the ATF16V8BQL-15SU is designed for operation in temperatures ranging from -40°C to 85°C. Its dimensions are 12.8mm in length and 2.35mm in height.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.50 | $0.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage range is 4.75 V to 5 V.
The operating temperature range is -40°C to 85°C.
It is available in a 20-pin SOIC package.
It has 150 logic gates.
The maximum internal frequency is 62 MHz.
Yes, it supports in-system programmability.
The maximum propagation delay is 15 ns.
