| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
7,000 pcs
|
7000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Frequency Range | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Shielding | |
| Tolerance | |
| Type | |
| Width |
The Abracon ASPI-7318-6R8M-T is a high current shielded power inductor in the ASPI-7318 series. It features a ferrite drum core with wirewound construction, providing inductance of 6.8 µH (±20% tolerance) tested at 200 kHz, 0.25 V, 0 A. The component offers a low maximum DC resistance of 60 mOhm and is rated for 4.5 A continuous current (Irms, 40°C temperature rise) with a saturation current of 8 A typical (20% inductance drop).
Designed for space-constrained power applications, this inductor handles high transient current spikes without saturation and exhibits ultra-low buzz noise due to composite construction. It operates over a temperature range of -55°C to 125°C and is suitable for frequencies up to 5.0 MHz.
The inductor is packaged in a surface mount nonstandard case measuring 7.3 x 6.8 x 3.0 mm, supplied in tape and reel with 1000 pieces per reel. It is RoHS3 compliant, 100% lead-free, and rated MSL Level 1 (unlimited).
| Qty | Low | High |
|---|---|---|
| 1+ | $0.80 | $0.80 |
| 10+ | $0.66 | $0.66 |
| 100+ | $0.54 | $0.54 |
| 1,000+ | $0.44 | $0.44 |
| 2,000+ | $0.42 | $0.42 |
| 3,000+ | $0.41 | $0.41 |
| 5,000+ | $0.39 | $0.39 |
| 7,000+ | $0.38 | $0.38 |
| 10,000+ | $0.37 | $0.37 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 6.8 µH with ±20% tolerance, tested at 200 kHz, 0.25 V, 0 A.
The continuous current (Irms) is 4.5 A typical causing a 40°C temperature rise. The saturation current (Isat) is 8 A typical, corresponding to a 20% inductance drop.
The maximum DC resistance (DCR) is 60 mOhm.
The inductor is surface mount in a nonstandard case measuring 7.3 mm x 6.8 mm x 3.0 mm (length x width x height).
The operating temperature range is -55°C to 125°C.
Yes, the inductor is shielded.
The MSL is Level 1 (unlimited), as stated in the datasheet.
