| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
113 pcs
|
113 pcs | On Request | 1 | On Request | On Request | 15+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Base Resonator | |
| Current | |
| Duty Cycle | |
| Frequency | |
| Frequency Stability | |
| Function | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Pins | |
| Operating Temperature | |
| Output | |
| Type | |
| Voltage | |
| Width |
The Abracon ASG2-LJ-156.250MHZ-513292 is a standard crystal oscillator (XO) delivering a 156.25 MHz LVDS output. It operates from a 2.5V supply (2.375V to 2.625V range) with a typical supply current of 40 mA. Frequency stability is ±35 ppm, and the device is rated for -40°C to +85°C operating temperatures.
This oscillator features an enable/disable function, with a high-impedance output when disabled. Phase jitter is specified at 0.5 ps typical and 1 ps maximum over a 12 kHz to 20 MHz bandwidth, making it suitable for low-jitter timing applications. The differential output voltage swing is 350 mV typical, with rise/fall times of 600 ps and a duty cycle of 45% to 55%.
The device comes in a miniature 2.5 x 2.0 x 1.0 mm ceramic surface-mount package with 6 pads (6-SMD, No Lead). It is RoHS3 compliant and rated MSL-1 (unlimited floor life). Storage temperature range is -55°C to +125°C.
Typical applications include networking equipment, SONET/SDH systems, WiMax/WLAN infrastructure, computing, phase-locked loops, and direct digital synthesis circuits.
The supply voltage range is 2.375V to 2.625V, with a nominal 2.5V.
It comes in a 6-SMD, No Lead package measuring 2.5 x 2.0 x 1.0 mm.
The operating temperature range is -40°C to +85°C.
Yes, it is RoHS3 compliant per the datasheet.
Frequency stability is ±35 ppm.
Phase jitter RMS is 0.5 ps typical and 1 ps maximum over a 12 kHz to 20 MHz bandwidth.
It provides LVDS differential output with a typical swing of 350 mV.
