| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
113 pcs
|
113 pcs | On Request | 1 | On Request | On Request | 15+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Base Resonator | |
| Current | |
| Duty Cycle | |
| Frequency | |
| Frequency Stability | |
| Function | |
| Height | |
| Length | |
| Mounting Type | |
| Operating Temperature | |
| Output | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Width |
The Abracon ASG2-LJ-125.000MHZ-513281 is a crystal-based XO (standard oscillator) that generates a 125 MHz LVPECL output. It operates from a 2.5V supply voltage (2.375V to 2.625V range) and draws a typical supply current of 40mA (65mA max).
Frequency stability is specified at ±35ppm maximum, with an overall stability of -50/+50 ppm inclusive of initial tolerance, temperature, voltage, load, and 15 years aging. Phase jitter is ultra-low at 0.5ps typical (12kHz to 20MHz bandwidth). The output has a 600ps rise/fall time and a duty cycle of 45% to 55%.
This oscillator is housed in a compact 2.5mm x 2.0mm x 1.0mm 6-SMD no-lead ceramic package, suitable for surface mount assembly. It features an enable/disable function and operates over the industrial temperature range of -40°C to +85°C. The device is RoHS3 compliant and has an MSL rating of 1 (unlimited).
125 MHz.
LVPECL.
2.5V nominal, with a range of 2.375V to 2.625V.
-40°C to +85°C.
±35ppm maximum, with overall stability of -50/+50 ppm inclusive of aging.
2.5mm x 2.0mm x 1.0mm, 6-SMD no lead.
Yes, RoHS3 compliant (low confidence, unverified).
