| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
250 pcs
|
250 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Base Resonator | |
| Current | |
| Disable Current | |
| Frequency | |
| Frequency Stability | |
| Function | |
| Height | |
| Length | |
| Mounting Type | |
| Operating Temperature | |
| Output | |
| Output Load | |
| Output Voltage High | |
| Output Voltage Low | |
| Package / Case | |
| RMS Phase Jitter | |
| Rise and Fall Time | |
| Start-up Time | |
| Storage Temperature | |
| Supply Current (Typical @ Vdd=3.3V, Load=15pF, F=25MHz) | |
| Supply Voltage | |
| Symmetry | |
| Tape & Reel | |
| Termination Style | |
| Tri-state Function | |
| Type | |
| Voltage | |
| Width | |
| aging (Nominal @ 1 year @25 °C±3 °C) | |
| aging (Nominal @ 5 years @25 °C±3 °C) | |
| rms_period_jitter (Typical @ Vdd=1.6 V -2.5 V, @25 °C±3 °C) | |
| rms_period_jitter (Typical @ Vdd=3.0 V -3.63 V, @25 °C±3 °C) |
The Abracon ASEDV-25.000MHZ-LC-T3 is a surface-mount crystal oscillator (XO) that provides a 25 MHz nominal frequency with HCMOS/LVCMOS output logic. It operates over a wide supply voltage range of 1.6V to 3.63V, making it suitable for low-power and battery-operated designs. Typical supply current is 5 mA at 3.3V with a 15 pF load.
The oscillator features a tri-state enable/disable function, with a disable current of only 10 µA maximum. It offers a frequency stability of ±50 ppm (per database) and an operating temperature range of -40°C to +85°C. The device is packaged in a hermetically sealed ceramic 4-SMD no-lead package measuring 3.2mm x 2.5mm x 1.2mm, suitable for automated assembly.
Typical applications include portable and wearable electronics, IoT devices, consumer electronics, industrial control and automation, and mobile communication systems. The part is RoHS3 compliant and has an MSL of Level 1.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.67 | $1.67 |
| 10+ | $1.44 | $1.44 |
| 25+ | $1.37 | $1.37 |
| 100+ | $1.24 | $1.24 |
| 250+ | $1.15 | $1.15 |
| 500+ | $1.12 | $1.12 |
| 3,000+ | $0.95 | $0.95 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The supply voltage range is 1.6V to 3.63V.
The operating temperature range is -40°C to +85°C.
It comes in a 4-SMD, No Lead package measuring 3.2mm x 2.5mm x 1.2mm.
Yes, it is RoHS3 compliant per the datasheet.
Typical supply current is 5 mA at Vdd=3.3V with a 15 pF load at 25 MHz.
Yes, it has an enable/disable tri-state function. Logic high or open enables oscillation; logic low disables output to high impedance.
