| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
45,000 pcs
|
45000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Aging | |
| Automotive Grade | |
| Base Resonator | |
| Current | |
| Frequency | |
| Frequency Stability | |
| Function | |
| Height | |
| Industrial Grade | |
| Lead Style | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Operating Temperature | |
| Output | |
| Output Load | |
| Output Voltage High | |
| Output Voltage Low | |
| RMS Phase Jitter | |
| Rise & Fall Time | |
| Standby Current | |
| Start-up Time | |
| Storage Temperature | |
| Supply Current | |
| Supply Voltage | |
| Symmetry | |
| Tape & Reel | |
| Tri-state Function | |
| Type | |
| Voltage | |
| Width |
The ASCO-8.000MHZ-EK-T3 is a surface-mount crystal oscillator (XO) from Abracon LLC, delivering a precise 8 MHz CMOS output. It is designed for general-purpose timing applications requiring a compact footprint and reliable performance.
This oscillator operates with a nominal supply voltage of 3.3V (2.97V to 3.63V range) and draws a supply current of 3.0mA to 4.5mA under typical load conditions. It offers a frequency stability of ±30ppm and an operating temperature range of -20°C to 70°C, making it suitable for a variety of commercial and industrial environments.
The device is housed in a 4-SMD, no-lead package measuring 1.60mm x 1.20mm x 0.70mm, ideal for space-constrained designs. It features a tri-state function for output enable/disable and provides fast start-up time of 2 ms with rise/fall times of 5 ns.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.30 | $2.30 |
| 10+ | $2.00 | $2.00 |
| 25+ | $1.81 | $1.81 |
| 100+ | $1.74 | $1.74 |
| 250+ | $1.51 | $1.51 |
| 500+ | $1.46 | $1.46 |
| 1,000+ | $1.39 | $1.39 |
| 3,000+ | $1.32 | $1.32 |
| 6,000+ | $1.25 | $1.25 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating temperature range is -20°C to 70°C.
The supply voltage is 2.97V to 3.63V with a nominal of 3.3V.
The frequency stability is ±30ppm.
It uses a 4-SMD, no-lead surface-mount package.
Yes, it is listed as RoHS3 compliant.
