AS4C64M16D3LA-12BIN The AS4C64M16D3LA-12BIN is a 1Gbit DDR3L SDRAM from Alliance Memory, Inc. It features an 800 MHz clock frequency and operates within an industrial temperature range.
Mfr Part #:

AS4C64M16D3LA-12BIN

Available from 1 distributors
Mfr Name: Alliance Memory, Inc.
Alliance Memory, Inc.
The AS4C64M16D3LA-12BIN is a 1Gbit DDR3L SDRAM from Alliance Memory, Inc. It features an 800 MHz clock frequency and operates within an industrial temperature range.
✓ Total Stock: 47 pcs
$ Price Range: $1.24

AS4C64M16D3LA-12BIN Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
47 pcs
On Request
47 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

AS4C64M16D3LA-12BIN Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Access Time
Clock Frequency
Memory Format
Memory Interface
Memory Organization
Memory Size
Memory Type
Mounting Type
Operating Temperature
SVHC Present
Supplier Device Package
Technology
Voltage
Write Cycle Time
View Similar Products (0)

AS4C64M16D3LA-12BIN Description

Short technical summary and product information.

The AS4C64M16D3LA-12BIN is a 1 Gigabit Double-Data-Rate-3 Low Voltage (DDR3L) Synchronous Dynamic Random-Access Memory (SDRAM) manufactured by Alliance Memory, Inc. This component is designed for high-speed operation, achieving data transfer rates of up to 1600 Mb/sec/pin.



Key electrical specifications include a fast clock rate of 800 MHz and a supply voltage range of 1.283V to 1.45V, with a nominal requirement of +1.35V. It is backward compatible with 1.5V ±0.075V supplies. The memory organization is 64M x 16 bits, with 8 internal banks for concurrent operation and an 8n-bit prefetch architecture.



This device operates within an industrial temperature range of -40°C to 95°C (TC). It is supplied in a compact 96-ball FBGA (8x13x1.0mm) package, suitable for surface mounting. The AS4C64M16D3LA-12BIN complies with JEDEC standards and is RoHS compliant, Pb and Halogen Free.



Features such as differential clock inputs (CK & CK#), bidirectional differential data strobe (DQS & DQS#), programmable burst lengths, and ZQ calibration contribute to its robust performance in various applications requiring high-density memory.

AS4C64M16D3LA-12BIN Quick Information

Product Type: DDR3L SDRAM
Canonical Name: AS4C64M16D3LA-12BIN DDR3L SDRAM
Subcategory: SDRAM - DDR3L

AS4C64M16D3LA-12BIN Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

AS4C64M16D3LA-12BIN Estimated Pricing

Qty Low High
1+ $1.24 $1.24

Estimated market price range - modelled values for guidance only, not live distributor offers.

AS4C64M16D3LA-12BIN Features

  • 1Gbit DDR3L SDRAM memory.
  • Operates at 800 MHz clock frequency.
  • Wide operating voltage range of 1.283V to 1.45V.
  • Industrial temperature range: -40°C to 95°C.
  • Compact 96-ball FBGA package.

AS4C64M16D3LA-12BIN Applications

  • Suitable for high-speed data processing.
  • Ideal for embedded systems.
  • Used in networking equipment.
  • Applicable in industrial automation.

AS4C64M16D3LA-12BIN FAQs

6 frequently asked questions generated from this part’s specifications.
What is the clock frequency of the AS4C64M16D3LA-12BIN?

The clock frequency is 800 MHz.

What is the operating temperature range for this DDR3L SDRAM?

The operating temperature range is -40°C to 95°C (TC).

What is the voltage supply for the AS4C64M16D3LA-12BIN?

The voltage supply is between 1.283V and 1.45V.

What package type is the AS4C64M16D3LA-12BIN supplied in?

It is supplied in a 96-VFBGA package.

Is the AS4C64M16D3LA-12BIN RoHS compliant?

Yes, it is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for this component?

The Moisture Sensitivity Level is 1 Unlimited.
