The Phihong USA AQ27E-59A-H is a 27W AC/DC wall adapter designed for various applications. It features a USB Type-C output connector and supports Power Delivery 3.0, offering versatile charging capabilities.
This adapter provides selectable DC output voltages of 5.0V, 9.0V, 12.0V, and 15.0V, with corresponding maximum currents of 3.0A, 3.0A, 2.25A, and 1.8A respectively. The maximum output power is 27W. It operates with an AC input voltage range of 90 to 264VAC and a frequency of 47 to 63Hz.
Key features include a fixed blade input connector suitable for European outlets, Class B EMI compliance, and protections such as over-voltage, over-current, and short-circuit auto-recovery. The adapter is designed for a wide operating temperature range of 0°C to +40°C.
Applications for this adapter include mobile phones, networking devices, and tablets. It meets Ecodesign/ErP Lot 7 (EU) 2019/1782 and CoC Version 5 Tier 2 compliance standards, making it suitable for use in Europe.
The adapter offers output voltages of 5.0V, 9.0V, 12.0V, and 15.0V with corresponding maximum currents of 3.0A, 3.0A, 2.25A, and 1.8A.
The maximum output power is 27W.
The adapter features a fixed blade input connector, suitable for European outlets.
The adapter operates within a temperature range of 0°C to +40°C.
Yes, it complies with Ecodesign/ErP Lot 7 (EU) 2019/1782.
It includes auto-recover protections for over-voltage, over-current, and short circuit conditions, as well as over-temperature latch-off protection.
