| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Case Color | |
| Current | |
| Dimensions | |
| Efficiency | |
| Form | |
| Height | |
| Industrial Grade | |
| Input Connector | |
| Input Type | |
| Insulation Resistance | |
| Length | |
| Medical Grade | |
| Military Grade | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Power (Watts) | |
| Region Utilized | |
| Standard Number | |
| Voltage | |
| Width |
The Phihong USA AQ15E-050A-H is a versatile 15W AC/DC wall mount adapter designed for various applications. It provides a stable 5V DC output at a maximum current of 3A, utilizing a USB Type-C receptacle for connectivity.
This adapter operates within a wide AC input voltage range of 90 to 264VAC and features a fixed blade input connector suitable for European outlets. Key electrical specifications include ±5% regulation, 150mV P-P ripple and noise, and an input current of 0.5A RMS maximum. It meets efficiency standards with a minimum of 74.4% at 115VAC and 81.8% at 230VAC, while maintaining a low no-load power consumption of 75mW.
Designed for reliability, the AQ15E-050A-H includes over-voltage and short-circuit protection with auto-recovery. It operates within a temperature range of 0°C to 40°C and meets safety and EMC standards including cULus 62368-1, EN 55032/CISPR 32 Class B, and EN 55035/CISPR 35.
The adapter has dimensions of 52.0mm x 40.0mm x 23.3mm and is housed in a black case. It complies with Ecodesign/ErP Lot 7 (EU) 2019/1782 and CoC Version 5 Tier 2 standards.
The adapter provides a regulated 5.0V DC output.
The unit operates safely between 0°C and +40°C.
The power supply delivers a maximum of 15 watts.
Yes, it features auto-recovery short circuit protection.
It is certified to cULus 62368-1 safety standards.
The unit terminates with a USB-C receptacle.
Peak-to-peak ripple and noise are limited to 150 millivolts.
