| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
60 pcs
|
60 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Current | |
| Current - Output | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Ratings | |
| Termination Style | |
| Topology | |
| Type | |
| Voltage | |
| Voltage (AC Input) | |
| Width |
The Mean Well USA APV-8-5 is a constant voltage LED driver designed for low-power LED lighting applications. It delivers a regulated 5V output at 1.4A, providing 7W of power with an efficiency of 74%. The driver accepts a nominal 90VAC input and uses an AC DC converter topology.
Protection features include over current protection (OCP), over voltage protection (OVP), and short circuit protection (SCP), ensuring reliable operation in demanding environments. The operating temperature range is -30°C to 70°C, and the unit carries an IP42 rating for protection against solid objects and dripping water.
Mechanically, the driver is designed for chassis mounting with wire lead terminations. Its compact dimensions are 60.0mm x 30.0mm x 23.5mm. The driver is approved by CCC, CE, and cURus agencies and is RoHS3 compliant with REACH unaffected status.
| Qty | Low | High |
|---|---|---|
| 1+ | $5.10 | $5.10 |
| 5+ | $4.90 | $4.90 |
| 10+ | $4.70 | $4.70 |
| 20+ | $4.50 | $4.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The APV-8-5 provides a constant voltage output of 5V at 1.4A.
It includes over current protection (OCP), over voltage protection (OVP), and short circuit protection (SCP).
The operating temperature range is -30°C to 70°C.
The IP rating is IP42.
Yes, it is listed as RoHS3 compliant.
It is designed for chassis mounting with wire lead terminations.
The dimensions are 60.0mm length, 30.0mm width, and 23.5mm height.
