| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
343 pcs
|
343 pcs | On Request | 1 | On Request | On Request | 14+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance | |
| Color | |
| Configuration | |
| Current | |
| Emitting Color | |
| Halogen Free | |
| Height (Max) | |
| Junction Temperature | |
| Lens Color | |
| Lens Size | |
| Lens Style | |
| Lens Transparency | |
| Millicandela Rating | |
| Mounting Type | |
| Operating Temperature | |
| Peak Forward Current | |
| Power Dissipation | |
| Reverse Current | |
| Reverse Voltage | |
| Storage Temperature | |
| Supplier Device Package | |
| Viewing Angle | |
| Voltage | |
| Wavelength |
This Kingbright APTD1608QBC/D is a blue surface-mount LED designed for indication and backlight applications. It features a compact 0603 (1608 Metric) package measuring 1.6mm x 0.8mm with a maximum height of 1.10mm.
The LED emits blue light with a peak wavelength of 460nm and a dominant wavelength of 465nm. It provides a typical luminous intensity of 200mcd at a forward current of 20mA and has a wide viewing angle of 40 degrees. The typical forward voltage is 3.3V.
Constructed with InGaN material, this device is suitable for various applications including status indicators, home appliances, and portable devices. It operates within a temperature range of -40°C to +85°C and is supplied in reels of 2000 pieces.
Environmental compliance includes RoHS3 status and a Moisture Sensitivity Level (MSL) of 3. The LED is halogen-free.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical forward voltage for the APTD1608QBC/D LED is 3.3V at 20mA.
The typical luminous intensity of the APTD1608QBC/D LED is 200mcd at 20mA.
The viewing angle of the APTD1608QBC/D LED is 40 degrees.
The operating temperature range for the APTD1608QBC/D LED is -40°C to +85°C.
Yes, the APTD1608QBC/D LED is RoHS3 compliant.
The APTD1608QBC/D LED is supplied in a 0603 (1608 Metric) SMD package.
