| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,476 pcs
|
1476 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance | |
| Color | |
| Configuration | |
| Current | |
| Halogen Free | |
| Height (Max) | |
| Junction Temperature | |
| Lens Color | |
| Lens Size | |
| Lens Style | |
| Lens Transparency | |
| Material | |
| Millicandela Rating | |
| Mounting Type | |
| Operating Temperature | |
| Peak Forward Current | |
| Power Dissipation | |
| Reverse Current | |
| Reverse Voltage | |
| Storage Temperature | |
| Supplier Device Package | |
| Viewing Angle | |
| Voltage | |
| Wavelength |
The Kingbright APTD1608CGCK is a green surface-mount device (SMD) chip LED designed for indication and backlight applications. It features a compact 0603 (1608 Metric) package measuring 1.6mm x 0.8mm with a maximum height of 1.10mm.
This LED emits green light with a dominant wavelength of 570nm and a peak emission wavelength of 574nm. It has a typical forward voltage of 2.1V at 20mA and a typical luminous intensity of 190mcd. The viewing angle is 60 degrees.
The device is constructed with AlGaInP on a GaAs substrate. It is rated for a maximum power dissipation of 75mW and a maximum forward current of 30mA. The operating temperature range is -40°C to +85°C.
Compliance includes RoHS3 status and a Moisture Sensitivity Level (MSL) of 3. The LED is suitable for various applications including status indicators, home and smart appliances, and wearable devices.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical forward voltage is 2.1V at 20mA.
The dominant wavelength is 570nm.
The viewing angle is 60 degrees.
The package type is 0603 (1608 Metric) Surface Mount.
Yes, it is RoHS3 Compliant.
The Moisture Sensitivity Level is 3.
