| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
940 pcs
|
940 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Configuration | |
| Current | |
| Forward Voltage | |
| Height (Max) | |
| Lens Color | |
| Lens Size | |
| Lens Style | |
| Lens Transparency | |
| Millicandela Rating | |
| Mounting Type | |
| Supplier Device Package | |
| Viewing Angle | |
| Voltage | |
| Wavelength |
This Kingbright APD3224SECK-F01 is a discrete surface mount LED with a vibrant orange color. It is designed for indication purposes and features a clear, colorless lens with a round, domed top. The LED operates with a typical forward voltage of 2.1V and a current of 20mA, producing a luminous intensity of 1600mcd at a dominant wavelength of 610nm.
The component is housed in a 1210 (3225 Metric) package, measuring 3.20mm in length and 2.40mm in width, with a maximum height of 2.40mm. Its viewing angle is 20 degrees, making it suitable for focused light emission applications. The lens size is 1.70mm in diameter.
This LED is classified under RoHS3 compliance and has a Moisture Sensitivity Level (MSL) of 1. Its standard configuration and clear lens make it a versatile component for various electronic designs requiring visual indication.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical forward voltage for the APD3224SECK-F01 LED is 2.1V at 20mA.
The typical luminous intensity of the APD3224SECK-F01 LED is 1600mcd when operated at 20mA.
The dominant wavelength for the APD3224SECK-F01 LED is 610nm.
The APD3224SECK-F01 LED is supplied in a 1210 (3225 Metric) SMD package.
The APD3224SECK-F01 LED is designed for surface mount installation.
