APBA3010SURKCGKC-GX The Kingbright APBA3010SURKCGKC-GX is a dual-color LED, emitting both green and red light. It features a 3-SMD, No Lead package and a surface mount, right-angle mounting type.
Mfr Part #:

APBA3010SURKCGKC-GX

Available from 5 distributors
Mfr Name: Kingbright
Kingbright
The Kingbright APBA3010SURKCGKC-GX is a dual-color LED, emitting both green and red light. It features a 3-SMD, No Lead package and a surface mount, right-angle mounting type.
✓ Total Stock: 10,167 pcs
$ Price Range: $0.99

APBA3010SURKCGKC-GX Available from 5 distributors

✓ Authorised
✓ Non-Authorised
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

APBA3010SURKCGKC-GX Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Configuration
Current
Height (Max)
Lens Color
Lens Size
Lens Style
Lens Transparency
Millicandela Rating
Mounting Type
Supplier Device Package
Viewing Angle
Voltage
Wavelength
View Similar Products (0)

APBA3010SURKCGKC-GX Description

Short technical summary and product information.

This Kingbright APBA3010SURKCGKC-GX is a discrete LED component capable of emitting both green and red light. It is housed in a compact 3-SMD, No Lead package, designed for surface mounting with a right-angle orientation. The LED offers a typical forward voltage of 2.1V for green and 1.95V for red, with a test current of 20mA for both colors. Its luminous intensity is rated at 70mcd for green and 80mcd for red. The dominant wavelengths are 570nm for green and 630nm for red, with peak wavelengths at 574nm (green) and 645nm (red). The lens is colorless and clear, with a rectangle shape and a domed top, providing a wide viewing angle of 140 degrees. The dimensions of the component are 3.00mm in length and 2.00mm in width, with a maximum height of 1.00mm. The lens size is 2.00mm x 1.00mm. This LED is suitable for various indication applications where dual-color functionality is required.

APBA3010SURKCGKC-GX Quick Information

Product Type: LED
Canonical Name: Kingbright APBA3010SURKCGKC-GX Dual Color LED
Subcategory: LED Indication - Discrete

APBA3010SURKCGKC-GX Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

APBA3010SURKCGKC-GX Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

APBA3010SURKCGKC-GX Features

  • Dual Green and Red light emission.
  • Surface mount, right-angle package.
  • Wide 140-degree viewing angle.
  • Clear, colorless domed top lens.
  • Compact 3.00mm x 2.00mm dimensions.

APBA3010SURKCGKC-GX Applications

  • Indicator for status signaling.
  • Dual color status indication.
  • Compact electronic devices.
  • General purpose LED applications.

APBA3010SURKCGKC-GX FAQs

6 frequently asked questions generated from this part’s specifications.
What colors does the Kingbright APBA3010SURKCGKC-GX LED emit?

The LED emits both Green and Red light.

What is the typical forward voltage for the Green and Red light of this LED?

The typical forward voltage is 2.1V for Green and 1.95V for Red.

What is the luminous intensity of the Green and Red LEDs?

The luminous intensity is 70mcd for Green and 80mcd for Red.

What is the viewing angle of the APBA3010SURKCGKC-GX LED?

The viewing angle is 140 degrees.

What package type is the Kingbright APBA3010SURKCGKC-GX LED?

It is a 3-SMD, No Lead package.

How is the APBA3010SURKCGKC-GX LED mounted?

It is a Surface Mount, Right Angle type.
