| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
24 pcs
|
24 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Halogen Free | |
| Mounting Type | |
| Operating Temperature | |
| Operating Voltage | |
| PSRR | |
| Storage Temperature | |
| Supply Current | |
| Tape & Reel |
The APA2068 from Anpec Electronics Corporation is a stereo audio power amplifier designed for applications requiring precise volume control and high-quality audio output. It features a DC volume control with 32 steps, allowing for fine adjustments from 20dB down to -80dB.
This amplifier can deliver up to 2.6W per channel into a 4W load at 5V in BTL mode, with a THD+N of less than 1.0%. It also supports a stereo single-end (SE) mode for headphone drive. The device operates within a voltage range of 4.5V to 5.5V and consumes a typical operating current of 9mA, with a low shutdown current of 1mA.
Integrated features include improved depop circuitry to eliminate turn-on and turn-off transients, short-circuit protection, and thermal shutdown protection. The APA2068 is available in a SOP-16P package with a thermal pad, suitable for surface mounting.
Key specifications include a PSRR of 60dB, SNR of 95dB, and an output noise of 20μV. The operating temperature range is -40°C to 85°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.87 | $1.87 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The APA2068 can deliver 2.6W per channel into a 4W load at 5V in BTL mode, and 1.8W into a 4W load with less than 1.0% THD+N.
The APA2068 operates within a supply voltage range of 4.5V to 5.5V.
The APA2068 features a precise DC volume control with 32 steps, adjustable by DC voltage with hysteresis, ranging from 20dB to -80dB.
The typical operating current for the APA2068 is 9mA.
The APA2068 is available in a SOP-16P package with a thermal pad.
The APA2068 operates within an ambient temperature range of -40°C to 85°C.
