Mfr Part #:

AOZ1281DI

Mfr Name: AOS

The AOZ1281DI is a 1.8A buck regulator from AOS, operating from a 3V to 26V input voltage range. It provides an adjustable output voltage down to 0.8V and features a fixed 1.5MHz PWM switching frequency.

✓ Total Stock: 4,311 pcs

$ Price Range: $0.59

AOZ1281DI Available from 2 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Smaxon Electronics ✓ Non-Authorised Inventory information	3,000 pcs On Request	3000 pcs	On Request	1	On Request	On Request	20+	On Request	On Request
Optech Co.,Limited ✓ Non-Authorised Inventory information	1,311 pcs On Request	1311 pcs	On Request	1	On Request	On Request	21+	On Request	On Request

AOZ1281DI Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	AOS
Efficiency	95 %
Mounting Type	Surface Mount
Output Current	1.8 A
Output Voltage	0.8 V
Tape & Reel	Yes

View Similar Products (0)

AOZ1281DI Description

Short technical summary and product information.

The AOZ1281DI is a high-efficiency, simple-to-use 1.8A buck regulator from Alpha and Omega Semiconductor. It is designed for a wide variety of applications, offering a flexible input voltage range from 3V to 26V and the ability to provide up to 1.8A of continuous output current.

The output voltage is adjustable down to 0.8V, making it suitable for diverse power management needs. The regulator operates with a fixed switching frequency of 1.5MHz in PWM mode, which helps in reducing the required inductor size. Key electrical features include internal compensation, internal soft start, and cycle-by-cycle current limit protection.

This buck regulator is housed in a compact, thermally-enhanced DFN 2x2, 8-lead package, suitable for surface mount applications. It also includes protection features such as short-circuit protection and thermal shutdown, enhancing its reliability in demanding environments.

Applications for the AOZ1281DI include point-of-load DC/DC conversion, set-top boxes, DVD drives, HDD, LCD monitors and TVs, cable modems, and telecom/networking/datacom equipment.

AOZ1281DI Quick Information

Product Type: Buck Regulator

Canonical Name: AOZ1281DI EZBuck™ 1.8 A Simple Buck Regulator

Subcategory: Power Management ICs

AOZ1281DI Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Lead Free: Compliant

AOZ1281DI Estimated Pricing

Qty	Low	High
1+	$0.59	$0.59

Estimated market price range - modelled values for guidance only, not live distributor offers.

AOZ1281DI Features

1.8A continuous output current capability.
Wide 3V to 26V input voltage range.
Output voltage adjustable down to 0.8V.
Fixed 1.5MHz PWM switching frequency.
Compact DFN 2x2, 8L package.

AOZ1281DI Applications

Point of load DC/DC conversion.
Set top boxes and DVD drives.
LCD monitors and televisions.
Telecom and networking equipment.

AOZ1281DI FAQs

7 frequently asked questions generated from this part’s specifications.

What is the operating voltage range of the AOZ1281DI?

The AOZ1281DI supports an input voltage range from 3 V to 26 V.

What package does the AOZ1281DI come in?

It is packaged in a DFN 2x2, 8L package.

What is the maximum output current of the AOZ1281DI?

The maximum continuous output current is 1.8 A.

What is the efficiency of the AOZ1281DI?

It has an efficiency of up to 95%.

What is the soft start time of the AOZ1281DI?

The soft start time is approximately 0.4 ms.

What is the operating temperature range of the AOZ1281DI?

It operates from -40 °C to +85 °C.

Is the AOZ1281DI RoHS compliant?

Yes, it is RoHS3 compliant.
