AO4478L The AO4478L is an N-Channel Enhancement Mode MOSFET from Alpha & Omega Semiconductor. It features a 30V drain-source voltage, 9A continuous drain current, and low on-resistance of 16mΩ typical.
Mfr Part #:

AO4478L

Available from 1 distributors
Mfr Name: Alpha&Omega Semicondu Ctor
Alpha&Omega Semicondu Ctor
The AO4478L is an N-Channel Enhancement Mode MOSFET from Alpha & Omega Semiconductor. It features a 30V drain-source voltage, 9A continuous drain current, and low on-resistance of 16mΩ typical.
✓ Total Stock: 2,190 pcs

AO4478L Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
2,190 pcs
On Request
2190 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

AO4478L Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Halogen Free
Mounting Type
Operating Temperature
Operating Temperature Range
Technology
View Similar Products (0)

AO4478L Description

Short technical summary and product information.

The AO4478L is an N-Channel Enhancement Mode MOSFET designed using advanced trench technology to provide low on-resistance and low gate charge. It is suitable for general purpose, PWM, and load switch applications. Key specifications include a maximum drain-source voltage of 30V, continuous drain current of 9A at 25°C, and typical on-resistance of 16mΩ at VGS=10V. The device is RoHS compliant and halogen free. It is offered in a surface-mount SOIC-8 package with an operating temperature range of -55°C to 150°C. The AO4478L is 100% UIS tested and 100% Rg tested for reliability.

AO4478L Quick Information

Product Type: N-Channel MOSFET
Series: AO4478L
Canonical Name: AO4478L N-Channel Enhancement Mode MOSFET
Subcategory: Single MOSFET

AO4478L Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 (Unlimited)
REACH Status: REACH Unaffected
Lead Free: Yes

AO4478L Features

  • 30V drain-source voltage rating.
  • 9A continuous drain current at 25°C.
  • Low on-resistance of 16mΩ typical.
  • RoHS compliant and halogen free.
  • Surface-mount SOIC-8 package.

AO4478L Applications

  • Suitable for general purpose switching.
  • Ideal for PWM and load switch applications.
  • Used in power management circuits.

AO4478L FAQs

7 frequently asked questions generated from this part’s specifications.
What is the maximum drain-source voltage of the AO4478L?

30V.

What is the continuous drain current rating?

9A at TA=25°C, 7A at TA=70°C.

What is the typical on-resistance?

16mΩ at VGS=10V, ID=9A.

What is the operating temperature range?

-55°C to 150°C.

Is the AO4478L RoHS compliant?

Yes, RoHS compliant and halogen free.

What package is the AO4478L available in?

SOIC-8 surface mount.

What is the gate threshold voltage?

1V min, 1.6V typ, 2V max.
