| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Protection Features | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Aimtec AMES75-36S277NZ is an enclosed AC/DC power supply designed for various applications. It offers a regulated 36V output with a current capability of 2.1A, delivering a total power of 76W. The converter operates with a wide input voltage range from 85 VAC to 305 VAC, ensuring flexibility in different power environments.
Key electrical specifications include an efficiency of 89% and an isolation voltage of 4000 VAC for enhanced safety. Protection features such as output short circuit, over-current, and over-voltage protection are included as standard. The operating temperature range is -30°C to 70°C with derating.
This series is suitable for ITE (Commercial) and household appliance applications. It is designed for chassis mounting, making it convenient for integration into various systems. The unit conforms to safety standards including 60335-1 and 62368-1, and holds approvals from CB, CE, EN, IEC, and UL.
The AMES75-277NZ series, to which this part belongs, is known for its cost-effectiveness, improved reliability, and performance due to material normalization and production automation. It offers a wide input voltage range and a broad output voltage selection from 5-48V.
The output voltage is 36V.
The output current is 2.1A.
The maximum power output is 76W.
The input voltage range is 85 VAC to 305 VAC.
The operating temperature range is -30°C to 70°C with derating.
It includes output short circuit, output over-current, and output over-voltage protection.
The dimensions are 99.0mm (Length) x 97.0mm (Width) x 30.0mm (Height).
