The Aimtec AMES75-NZ series AC-DC converter, model AMES75-051515TNZ, is an enclosed unit designed for reliable power conversion. It accepts a universal input voltage range of 90-264VAC and provides a regulated 5V output, with an adjustable range of 4.5-5.5V. This converter is rated for a maximum output current of 14A, delivering up to 72W of power.
Designed for demanding environments, the AMES75-051515TNZ operates within a temperature range of -30°C to 70°C. It offers high isolation voltage of 4000VAC for enhanced system safety and reliability. Protection features include output short circuit, over-current, and over-voltage protection as standard.
With a chassis mount type, this converter is suitable for various industrial and commercial applications. Its dimensions are 129.0mm x 97.0mm x 30.0mm. The series also boasts a high MTBF of 600,000 hours, contributing to its suitability for critical systems.
The nominal output voltage is 5V, adjustable from 4.5V to 5.5V.
The maximum output current is 14A.
The input voltage range is 90-264 VAC or 127-370 VDC.
The operating temperature range is -30°C to 70°C with derating.
It includes output short circuit, over-current, and over-voltage protection.
