| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Aimtec AMES50-5S277NZ is an enclosed AC/DC power converter designed for reliability and cost-effectiveness. It operates with a universal input voltage range of 85-305VAC and provides a regulated 5V DC output with a maximum current of 10A, delivering up to 50W of power.
Key electrical specifications include an efficiency of 86% at 230VAC and a typical ripple and noise of 80mVp-p for the 5V output. The converter features high isolation of 4000VAC, enhancing system safety and reliability. It is designed for operation within an ambient temperature range of -30°C to 70°C, with derating applied at higher temperatures.
Mechanically, this unit is designed for chassis mounting and has dimensions of 99.0mm x 82.0mm x 30.0mm. It complies with safety standards such as 60335-1 and 62368-1. The AMES50-5S277NZ series includes standard protections like output short circuit, over-current, and over-voltage protection, contributing to its suitability for various industrial and commercial applications.
The output voltage is 5V.
The maximum output current is 10A.
The power rating is 50W.
The input voltage range is 85-305VAC.
The operating temperature range is -30°C to 70°C.
The isolation voltage is 4000VAC.
It is a chassis mount type.
