| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Aimtec AMES350-12SNZ-P is an enclosed AC-DC converter designed for reliable power conversion. It offers a universal input voltage range of 90-264VAC and a regulated 12V output, capable of delivering up to 348W of power with an efficiency of 85% at 230VAC.
This converter is suitable for various applications, including household appliances and ITE (Commercial) equipment. It features a chassis mount type for easy integration into systems. The operating temperature range is -30°C to 70°C, with derating applied. Key electrical specifications include an output current of 29A and an isolation voltage of 4000VAC.
Protection features include output short circuit, over-current, over-voltage, and over-temperature protection. The unit also offers surge immunity up to 300VAC for 5 seconds. Its dimensions are 215.0mm in length, 115.0mm in width, and 30.0mm in height.
The output voltage is 12V.
The maximum output power is 348W.
The operating temperature range is -30°C to 70°C with derating.
It uses chassis mount.
The efficiency is 85% at 230VAC.
The dimensions are 215.0mm x 115.0mm x 30.0mm.
