| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Package / Case | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Aimtec AMEOF8-12SL277NZ-120 is an 8W AC DC converter from the AMEOF8 series, designed for efficiency and reliability. It features a universal input voltage range of 85-305 VAC and a 12V DC output voltage, capable of delivering up to 670mA.
This converter is housed in an open frame package with through-hole mounting, making it suitable for various industrial and commercial applications. It operates across a wide temperature range of -40°C to 85°C, ensuring performance in demanding environments. Key electrical specifications include an efficiency of 76% at 230VAC and an isolation voltage of 3000VAC.
Safety and reliability are enhanced by features such as output short circuit protection, over-current protection, and over-voltage protection. The series also boasts a high MTBF of 300,000 hours. Compliance with standards like 60335-1 and 62368-1 is noted, along with RoHS3 compliance.
Applications include household appliances and ITE commercial equipment where space constraints and reliable power conversion are critical. The compact dimensions (44.5mm x 22.5mm x 15.0mm) further facilitate integration into designs.
The input voltage range is 85 to 305 VAC or 100 to 430 VDC.
The output voltage is 12V and the output current is 0.67A.
The operating temperature range is -40°C to 85°C.
The isolation voltage is 3000VAC.
The package is a 16-SIP Module with 6 leads and through-hole mounting.
The efficiency is 76%.
The MTBF is 300,000 hours.
