The Aimtec AMEOF8-09SL277NZ-120 is an 8W AC-DC converter designed for various applications requiring a reliable power supply. It features a universal input voltage range of 85-305VAC and a 9V DC output voltage.
This converter boasts an efficiency of 75% and operates within an extended temperature range of -40°C to 85°C, making it suitable for demanding environments. The open frame design and through-hole mounting facilitate integration into compact systems.
Key electrical specifications include an isolation voltage of 3000VAC and a maximum ripple and noise of 150mVp-p. The device is built with safety and reliability in mind, offering features such as output short circuit, over-current, and over-voltage protection. Its dimensions are 44.5mm in length, 22.5mm in width, and 15.0mm in height.
Suitable for industrial controls, instrumentation, and smart home applications, the AMEOF8-09SL277NZ-120 meets standards such as 60335-1 and 62368-1. It is designed for applications requiring a stable and efficient power conversion solution.
85-305 VAC or 100-430 VDC.
16-SIP Module, 6 Leads.
-40°C to 85°C.
9V at 0.88A.
3000 VAC.
75%.
300,000 hours.
