| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Package / Case | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Aimtec AMEOF8-09S277NZ-120 is an 8W AC-DC converter designed for various industrial and smart home applications. It offers a universal input voltage range of 85-305VAC and a DC voltage input range of 100-430VDC.
This converter provides a single 3.3V output with a maximum current of 1.60A, delivering up to 5.28W of power. It boasts high efficiency up to 79% and features 3000VAC isolation for enhanced reliability and safety. The operating temperature range is -40°C to 85°C, making it suitable for demanding environments.
Key features include output short circuit, over-current, and over-voltage protection. The open frame package with through-hole mounting is designed for integration into systems with size constraints. It meets safety standards such as 60335-1 and 62368-1.
Applications include industrial controls, instrumentation, power grid, and telecom systems where compact and reliable power conversion is essential.
The input voltage range is 85 to 305 VAC or 100 to 430 VDC.
This converter provides a 3.3V output voltage with a maximum current of 1.60A.
The maximum output wattage is 5.28W for the 3.3V model, with an overall power rating of 8W.
The operating temperature range is from -40°C to 85°C.
The converter offers a high isolation voltage of 3000 VAC.
