The Aimtec AMEOF5-24SL277NZ is a highly efficient 5W AC-DC converter designed for various applications. It offers a universal input range of 85-305VAC or 70-430VDC, making it versatile for different power sources.
This converter provides a stable 24V output with a maximum current of 210mA. Key electrical specifications include a typical efficiency of 79% at 230VAC and a low ripple and noise of 150mV(p-p) maximum. It also features essential protections such as output short circuit and over-current protection with auto-recovery.
Designed for reliability, the AMEOF5-24SL277NZ boasts an isolation voltage of 3000VAC and a high MTBF of 300,000 hours. The operating temperature range is -40°C to +85°C, with derating applied outside this range. Its compact dimensions (35.0mm x 18.0mm x 11.0mm) and through-hole mounting make it suitable for applications with dimensional constraints.
This series is suitable for industrial control, electric power, instrumentation, and smart home applications. It can be configured to meet CISPR32/EN55032 Class A or Class B standards.
The input voltage range is 85 to 305 VAC or 70 to 430 VDC.
The output voltage is 24V.
The output power is 5W.
The isolation voltage is 3000VAC.
The operating temperature range is -40°C to 85°C with derating.
The package is a 12-SIP Module with 6 leads, through-hole mounting.
It includes output short-circuit protection (hiccup, continuous, auto recovery) and output over-current protection (auto recovery).
