The Aimtec AMEOF5-12S277NZ-420 is a highly efficient 5W AC-DC converter designed for various applications. It offers a universal input voltage range of 85-305VAC and 70-430VDC, providing flexibility for global use.
This converter delivers a stable 12V output with a maximum current of 420mA. Key electrical specifications include a typical efficiency of 77% at 230VAC, an isolation voltage of 3000VAC, and a maximum ripple and noise of 150mVp-p. It is equipped with auto-recovery for over-current protection and hiccup/continuous/auto-recovery for short-circuit protection.
Designed for reliability, the AMEOF5-12S277NZ-420 operates across a broad temperature range from -40°C to +85°C. Its physical dimensions are 35.0mm in length, 11.0mm in width, and 18.0mm in height. The unit is housed in a 12-SIP module with 6 leads and is designed for through-hole mounting.
This series is suitable for industrial control, electric power, instrumentation, and smart home applications. It meets safety standards such as 60335-1 and 62368-1, and carries cURus approval.
The input voltage range is 85 to 305 VAC and 70 to 430 VDC.
The output voltage is 12 V and the maximum output current is 0.42 A.
The operating temperature range is -40°C to 85°C.
The package is a 12-SIP Module with 6 leads and through-hole mounting.
It provides 3000 VAC input-to-output isolation.
It includes over-current protection and short-circuit protection, both with auto recovery.
