The Aimtec AMEOF45-12SJZ is a compact, open-frame AC/DC converter designed for versatile power supply applications. It accepts a universal input voltage range of 85-264VAC and provides a regulated 12V output with a maximum current of 3.75A, delivering up to 45W of power.
Key electrical specifications include a high isolation voltage of 3000VAC, an efficiency of 84% at 230VAC, and low ripple and noise of 100mVp-p. The converter includes protection features such as over-current and over-voltage protection for enhanced reliability. It operates within a temperature range of -25°C to 70°C.
Designed for chassis mounting, this open-frame converter is suitable for various industrial, office, and civil applications. Its features make it a reliable choice for powering devices like modems, printers, and telecom equipment.
The AMEOF45-12SJZ accepts universal AC input from 85-264VAC and also DC input from 100-370VDC.
It is an open-frame chassis mount module measuring 76.2mm x 50.8mm x 30.0mm.
The operating temperature range is -25°C to 70°C.
The output voltage is 12V nominal.
Typical efficiency is 84% at 230VAC input.
Isolation voltage is 3000VAC.
It includes over current protection (≥150% of Iout) and over voltage protection (≤20VDC for 12V output).
