The Aimtec AMEM5-5SY is a compact AC/DC converter designed for board-mount applications. It provides a 5V output voltage at 1A, delivering 5W of power.
Key electrical specifications include a wide input voltage range of 85-264 VAC (or 120-370 VDC), an efficiency of 73.6% at 230VAC, and 4000VAC of I/O isolation. The converter offers continuous short circuit protection, over-load protection (≥110% of Iout), and over-voltage protection (120-190% rated Vout).
This converter is housed in a 5-DIP module package and is designed for Through Hole mounting. It operates within a temperature range of -25°C to 70°C. The AMEM5-5SY is suitable for ITE (Commercial) applications and carries CE, cURus approval agency certifications.
The AMEM5-5SY provides a 5V output voltage and a maximum output current of 1A.
The input voltage range for the AMEM5-5SY is 85-264 VAC or 120-370 VDC.
The AMEM5-5SY converter has a power rating of 5W.
The AMEM5-5SY provides 4000VAC of I/O isolation.
The operating temperature range for the AMEM5-5SY is -25°C to 70°C.
The AMEM5-5SY is mounted using the Through Hole method.
