The Aimtec AMEL6-3.3SVZ-ST is an AC DC converter designed for ITE (Commercial) applications. It provides a stable 3.3V output voltage with a maximum current of 1.25A, delivering a total power of 4.1W.
This converter operates with a wide input voltage range of 85-264 VAC or 100-370 VDC, making it suitable for various power environments. It boasts an efficiency of 70% and an isolation voltage of 4 kV. The operating temperature range is -40°C to 70°C with derating.
Designed for easy integration, the AMEL6-3.3SVZ-ST features a chassis mount type and comes in an enclosed configuration. Its dimensions are 75.9mm x 31.5mm x 24.1mm. The product complies with standard numbers 60950-1 and 62368-1.
The output voltage is 3.3V.
The power rating is 4.1W.
The input voltage range is 85-264 VAC or 100-370 VDC.
The operating temperature range is -40°C to 70°C with derating.
The dimensions are 75.9mm x 31.5mm x 24.1mm.
The isolation voltage is 4 kV.
It complies with standard numbers 60950-1 and 62368-1.
