The Aimtec AMEL5-9S277NZ is an enclosed AC-DC converter designed for industrial applications. It offers a regulated 9V output with a maximum current of 550mA, providing 5W of power.
The converter accepts a universal input voltage range of 85 to 305VAC, making it suitable for various power grids and industrial control systems. It operates within a temperature range of -40°C to 70°C and provides 4000VAC isolation for enhanced system safety and reliability.
Key electrical specifications include 74% efficiency at 230VAC and a low ripple and noise level of 100mV(p-p) maximum. The unit is housed in a 4-DIP module package and is designed for through-hole mounting.
Protection features include output short circuit, over-current, and over-voltage protection as standard. The high MTBF of 300,000 hours indicates robust performance and longevity.
The input voltage range is 85 to 305VAC.
The AMEL5-9S277NZ has a 9V output voltage and a maximum output current of 550mA.
The power rating is 5W.
The operating temperature range is -40°C to 70°C.
The isolation voltage is 4000VAC.
It is in a 4-DIP Module package.
