The Aimtec AMEL45-48SJZ-STD is an enclosed AC-DC converter designed for reliable power conversion. It offers a universal input voltage range of 85-264VAC and a DC input range of 100-370VDC, making it suitable for various global applications.
This converter provides a regulated 48V output with a maximum current of 940mA, delivering up to 45W of power. It boasts a high efficiency of 87% at 230VAC and features a robust isolation voltage of 4000VAC for enhanced system safety. The operating temperature range is -40°C to 70°C, with derating applied outside this range.
Designed for ease of integration, the AMEL45-48SJZ-STD is suitable for DIN rail mounting. It includes essential protection features such as output short circuit, over-current, and over-voltage protection. The converter is compliant with safety standard 62368-1 and approved by cURus.
Key electrical specifications include a low ripple and noise of 120mVp-p (max) measured at a 20MHz bandwidth, and a high MTBF of 300,000 hours. Its dimensions are 136.9mm in length, 70.1mm in width, and 37.8mm in height.
The output voltage is 48V.
The maximum output current is 940 mA.
The power rating is 45W.
The operating temperature range is -40°C to 70°C.
It is designed for DIN rail mounting.
The dimensions are 136.9mm in length, 70.1mm in width, and 37.8mm in height.
It complies with safety standard 62368-1 and is approved by cURus.
