| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Aimtec AMEL45-15SJZ is an enclosed AC/DC converter designed for commercial ITE applications. It offers a regulated 15V output at 3A, providing a total power of 45W. The converter accepts a wide universal input voltage range of 85-264 VAC and 100-370 VDC.
Key electrical specifications include an efficiency of 85%, line regulation of ±0.5%, and load regulation of ±1%. It provides 4000VAC isolation and features protection against output short circuit, over-current, and over-voltage. The operating temperature range is -40°C to 70°C with derating.
This AC/DC converter is suitable for through-hole mounting and comes in a 4-DIP Module package. Its robust design and features make it a reliable choice for various industrial and communication systems.
The output voltage is 15V and the output current is 3A, providing 45W of power.
The input voltage range is 85-264VAC or 100-370VDC.
The efficiency is 85%.
The isolation voltage is 4000VAC.
The converter is housed in a 4-DIP through-hole module with dimensions 87.0mm x 52.0mm x 29.5mm.
The operating temperature range is -40°C to 70°C with derating.
The MTBF is 300,000 hours.
