| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Type | |
| Voltage | |
| Width |
The Aimtec AMEL15-9SJZ is an enclosed AC/DC converter designed for various applications. It offers a universal input voltage range of 85-264 VAC and a DC input range of 100-370 VDC, making it suitable for global use.
This converter provides a single 9V output with a maximum current of 1.66A, delivering up to 15W of power. It boasts an efficiency of 77% at 230VAC and operates reliably within a wide temperature range of -40°C to 70°C. Key electrical features include 4000 VAC isolation for enhanced safety and typical ripple and noise of 50mVp-p.
The AMEL15-9SJZ is designed for through-hole mounting and comes in a 4-DIP Module package. Its compact dimensions are 53.8mm in length, 28.8mm in width, and 23.5mm in height. The converter includes standard protections such as output short circuit, over-current, and over-voltage protection, along with a high MTBF of 300,000 hours for improved system reliability.
Applications for this series include ITE (Commercial) use, grid power, industrial controls, instrumentation, and communication systems. It is certified by CE and cURus.
The input voltage range is 85-264 VAC or 100-370 VDC.
The output voltage is 9V with a maximum current of 1.66A.
The power rating is 15W.
The operating temperature range is -40°C to 70°C.
The isolation voltage is 4000 VAC.
The typical ripple and noise is 50mVp-p at a 20MHz bandwidth.
It is in a 4-DIP Module package.
