| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Package / Case | |
| Power (Watts) | |
| Protection Features | |
| Type | |
| Voltage | |
| Width |
The Aimtec AMEL15-24SJZ is an enclosed AC/DC converter designed for various applications. It provides a 15W output power with a regulated 24V output voltage and a maximum current of 625mA. The converter operates with a universal input voltage range of 85-264 VAC and 100-370 VDC, making it suitable for global use.
Key electrical specifications include an efficiency of 81% and an isolation voltage of 4000 VAC. It also features output short circuit, over-current, and over-voltage protection for enhanced system safety and reliability. The operating temperature range is -40°C to 70°C, and it has a low ripple and noise characteristic of 50mV(p-p).
This AC/DC converter is designed for through-hole mounting and comes in a 4-DIP Module package. Its features, including universal input and robust protection, make it a reliable choice for industrial controls, instrumentation, and other commercial applications.
The output voltage is 24V.
The input voltage range is 85-264 VAC and 100-370 VDC.
The power rating is 15W.
The operating temperature range is -40°C to 70°C.
It uses through-hole mounting.
