The Aimtec AMEL15-15SJZ is an enclosed AC/DC converter designed for board mount applications. It features a universal input voltage range of 85-264VAC and provides a regulated 15V output at up to 1A, delivering a maximum of 15W.
This converter boasts an efficiency of 81% and operates within a temperature range of -40°C to 70°C, with derating applied. It offers high isolation voltage of 4000VAC for enhanced reliability and system safety. Protection features include output short circuit, over-current, and over-voltage protection.
The AMEL15-15SJZ is suitable for ITE (Commercial) applications and is housed in a 4-DIP Module package with through-hole mounting. Its dimensions are 53.8mm in length, 28.8mm in width, and 23.5mm in height.
Key specifications include a typical MTBF of 300,000 hours and low ripple and noise of 50mV(p-p). The part is compliant with RoHS3 standards.
The input voltage range is 85 to 264 VAC.
The output voltage is 15V.
The maximum output current is 1A.
The power rating is 15W.
The operating temperature range is -40°C to 70°C, with derating.
The isolation voltage is 4000VAC.
The package type is 4-DIP Module.
