| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Aimtec AMEL10-5S277NZ-ST is an enclosed AC/DC converter designed for various applications. It provides a regulated 5V output with a maximum power of 6.6W and a current rating of 2A. The converter accepts a universal input voltage range of 85-305VAC and features a high isolation voltage of 4000VAC, enhancing system safety and reliability.
With an operating temperature range of -40°C to 70°C, this series is suitable for demanding environments. It boasts an efficiency of 72% and includes features like universal input. The physical dimensions are 76.0mm in length, 31.5mm in width, and 27.8mm in height. Mounting is via chassis mount, making it adaptable for various system integrations.
This AC/DC converter is ideal for applications requiring stable power conversion with robust isolation and a wide operating temperature range. Its enclosed type and chassis mount design facilitate integration into industrial and commercial equipment.
85-305VAC.
5V at 2A (6.6W).
4000VAC.
-40°C to 70°C.
72%.
76.0mm x 31.5mm x 27.8mm, chassis mount.
6.6W.
