| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| SVHC Present | |
| Type | |
| Voltage | |
| Width |
The Aimtec AMEL10-24S277NZ-ST is an enclosed AC/DC converter designed for industrial applications. It offers a universal input voltage range of 85-305VAC and provides a single regulated output of 24V with a maximum current of 450mA, delivering 10W of power.
This converter operates efficiently at 82% and features high isolation voltage of 4000VAC. Its wide operating temperature range of -40°C to 70°C ensures performance in demanding environments. The unit is chassis mountable and includes features such as universal input.
Key specifications include a compact size with dimensions of 76.0mm x 31.5mm x 27.8mm. It is suitable for ITE (Commercial) applications and offers protection features standard for the series. The AMEL10-24S277NZ-ST is designed for reliability and cost-effectiveness in system designs.
The output voltage is 24V.
The input voltage range is 85-305VAC.
The maximum power output is 10W.
The operating temperature range is -40°C to 70°C.
The isolation voltage is 4000VAC.
It is chassis mounted.
