The Aimtec AMEL10-15SJZ is an enclosed AC/DC converter designed for ITE (Commercial) applications. It delivers 11W of power with a single 15V output and a maximum current of 700mA.
This converter operates with a universal input voltage range of 85-264 VAC or 100-370 VDC, offering flexibility in power source selection. It boasts an efficiency of 81% and features universal input capabilities. The operating temperature range is -40°C to 70°C with derating.
With dimensions of 53.8mm x 28.8mm x 19.0mm, the AMEL10-15SJZ is designed for Through Hole mounting in a 4-DIP Module package. It is compliant with RoHS3 standards and has an MSL of 1 Unlimited.
The input voltage range is 85-264 VAC or 100-370 VDC.
The output is 15V at 700mA.
-40°C to 70°C with derating.
4-DIP Module with through-hole mounting.
3 kV.
81%.
11W.
