The Aimtec AMED75-48SJZ is an enclosed AC-DC converter designed for reliable power conversion in industrial environments. It offers a universal input voltage range of 90-264VAC and provides a stable 48V output with a maximum power of 75W. This converter is built to withstand harsh conditions, operating effectively within a temperature range of -30°C to +70°C.
Key features include high isolation voltage of 4000VAC, low ripple and noise (150mVp-p max), and built-in protections for over-current, over-voltage, and over-temperature. With an efficiency of 90% and a Mean Time Between Failures (MTBF) of 300,000 hours, it ensures dependable performance and longevity.
The AMED75-48SJZ is designed for easy integration, featuring a DIN rail mounting type. Its compact dimensions (125.0mm x 87.4mm x 32.0mm) make it suitable for space-constrained applications. This converter complies with international standards such as IEC/EN/UL62368, IEC/EN/UL60335, GB4943, and UL508, making it a versatile choice for industrial control equipment, machinery, and various other applications.
90-264 VAC.
48V.
75W.
-30°C to +70°C.
DIN Rail mounting.
4000VAC.
Over current protection with self-recovery and over voltage protection with manual-recovery.
